Delivers multiyear flow assurance in offshore wells
What is Sorb Ultra?
Sorb Ultra is a chemical-infused proppant that can address your need for multiyear, offshore reservoir flow assurance. The newest addition to our field-proven Sorb product line, Sorb Ultra is designed for offshore applications and can withstand high closure pressures for deepwater wells. It is added during stimulation to mitigate or eliminate the need for an expensive and potentially damaging intervention due to scale, paraffin, bacteria, or asphaltene deposition.
How it works
High-strength Sorb Ultra particles are engineered to serve as a conventional, medium-strength proppant but with an added benefit – the ability to provide long-term flow assurance. Delivered as part of an integrated StimPlus™ service combining stimulation services and flow assurance chemistry, the Sorb Ultra materials are placed in the near-wellbore environment and reservoir as part of the proppant pack and the chemicals are only released when needed.
Why apply Sorb Ultra?
Think about it. You can delay or prevent costly production interruptions. You can provide inhibition in the reservoir for scale, paraffin and asphaltene. You can achieve long-term, multiyear inhibition. And, you can simplify the transition into production chemistry programs. In short, Sorb Ultra delays, reduces, and/or eliminates the need for subsequent costly well interventions – improving your well’s economics.
Sorb Ultra Offerings
Current offerings include the following:
Flow Assurance:
-ScaleSorb™ Ultra for inorganic scale;
-SaltSorb™ Ultra for salt deposition;
-ParaSorb™ Ultra for paraffin deposition;
-AsphaltSorb™ Ultra for asphaltene deposition.
Integrity Management:
-CorrSorb™ Ultra for corrosion control;
-BioSorb™ Ultra for bacterial control.
Applications
-Deepwater and ultradeepwater oil and gas wells;
-Wells with high closure pressures (>8,000 PSI).
ScaleSorb Ultra Solid Scale Inhibitors
The Baker Hughes ScaleSorb™ Ultra solid scale inhibitors are high-strength controlled-release additives that slowly desorb from the proppant pack to provide immediate and long-term protection against scale deposition. ScaleSorb Ultra treatments minimize the risk of lost production and can signifcantly delay expensive interventions in deepwater and ultra-deepwater wells.
Like the Baker Hughes Sorb™ products, the Sorb™ Ultra family of products delivers multiyear inhibition. Unlike Sorb products, Sorb Ultra products withstand high closure pressures.
The Baker Hughes Sorb Ultra family of solid specialty chemicals safely and effciently inhibits downhole deposition or tubular damage with slow-releasing and long-lasting chemicals that are adsorbed onto a solid substrate that is specially engineered for high-pressure deepwater environments and then pumped deep into the formation.
The amount of Sorb Ultra material added to the proppant is based on crush and conductivity tests done in preparation for the job, and on the desired life of the treatment. When the well begins to produce, the scale inhibitor slowly desorbs into the water phase of the production, inhibiting scale deposition in the near-wellbore area and tubing. Because the product is dry and inert, it will not contribute to chemical runoff if spilled. This is environmentally preferable to conventional liquid additives or batch- and continuous-injection liquid chemical systems.
ScaleSorb Ultra inhibitor is a Baker Hughes StimPlus™ services product and is compatible for use with common stimulation fluids. StimPlus products are added to the stimulation fluid and placed deep into the formation, where they can prevent deposition and costly production problems. Our service includes pre-stimulation system analysis, stimulation fluid compatibility, coordination with pressure pumping services, and post-frac monitoring services to minimize flow assurance issues and protect wellbore assets.
Applications
Deepwater and ultra-deepwater oil and gas wells
Features and benefits
Reduced costs
– Reduces downtime caused by deposition in the near wellbore;
– Eliminates or reduces costly offshore interventions.
Extended flow assurance
– Safely and efficiently inhibits downhole scale deposition with slow-release, long-lasting chemicals;
– Works on produced fluids before reaching the near-wellbore area;
– Includes monitoring using analytical methods.
Comprehensive well protection
– Contains broad-use scale inhibitors.
Simple application
– Permits multiple applications including gravel packs, frac packs, or fractures in new or existing wells;
– Ensures reliable application in high-pressure deepwater environments with specially engineered solid substrate;
– Offers compatibility with most fracturing fluids, as determined by lab analysis.
Qualified member of the SmartCare family of environmentally responsible solutions
– Minimizes environmental impact without sacrificing performance;
– Increases transparency of chemical composition to stakeholders.
CorrSorb Ultra Solid Corrosion Inhibitor
The Baker Hughes CorrSorb™ Ultra solid corrosion inhibitor is a high-strength controlledrelease additive that slowly desorbs from the proppant pack to provide immediate and longterm protection against corrosion to downhole assets.
CorrSorb Ultra treatments minimize the risk of lost production and can signifcantly delay expensive interventions in deepwater and ultra-deepwater wells.
Like the Baker Hughes Sorb™ products, the Sorb™ Ultra family of products delivers multiyear inhibition. Unlike Sorb products, Sorb Ultra products withstand high closure pressures. The Baker Hughes Sorb Ultra family of solid specialty chemicals safely and effciently inhibits downhole deposition or tubular damage with slow-releasing and long-lasting chemicals that are adsorbed onto a solid substrate that is specially engineered for high-pressure deepwater environments and then pumped deep into the formation.
The amount of Sorb Ultra material added to the proppant is based on crush and conductivity tests done in preparation for the job, and on the desired life of the treatment. When the well begins to produce, the corrosion inhibitor slowly desorbs into the water phase of the production, inhibiting corrosion deposition in the near-wellbore area and tubing. Because the product is dry and inert, it will not contribute to chemical runoff if spilled. This is environmentally preferable to conventional liquid additives or batch- and continuous-injection liquid chemical systems.
CorrSorb Ultra inhibitor is a Baker Hughes StimPlus™ services product and is compatible for use with common stimulation fluids. StimPlus products are added to the stimulation fluid and placed deep into the formation, where they can prevent deposition and costly production problems. Our service includes pre-stimulation system analysis, stimulation fluid compatibility, coordination with pressure pumping services, and post-frac monitoring services to minimize flow assurance issues and protect wellbore assets.
Applications
Deepwater and ultra-deepwater oil and gas wells
Features and benefits
Reduced costs
– Reduces downtime caused by corrosion in the near wellbore;
– Eliminates or reduces costly offshore interventions.
Extended flow assurance
– Safely and effciently inhibits carbon dioxide and hydrogen sulfde with slow-release, long-lasting chemicals;
– Works on produced fluids before reaching the near-wellbore area;
– Includes monitoring for residual inhibition.
Comprehensive well protection
– Contains a broad-use, water-soluble filming corrosion inhibitor.
Simple application
– Permits multiple applications including gravel packs, frac packs, or fractures in new or existing wells;
– Ensures reliable application in high-pressure deepwater environments with speciallym engineered solid substrate;
– Offers compatibility with most fracturing fluids, as determined by lab analysis.
Qualifed member of the SmartCare family of environmentally responsible solutions
– Minimizes environmental impact without sacrificing performance;
– Increases transparency of chemical composition to stakeholders.
